Product features:
DMX512 protocol; Can be connected to the same bus control as any device that complies with the protocol;
Adopting DMX512 standard protocol signal interface;
Equipped with 8 relays, each with a maximum of 16A/250VA, of which 4 include normally open and normally closed outputs, providing flexible application;
During relay control, each relay occupies one DMX512 address, totaling eight DMX512 addresses;
Provide manual button control mode, convenient and fast for on-site and emergency use;
Suitable for stage lighting, landscape, advertising, offices, hotels, engineering, etc.
Technical parameters:
Input voltage: DC24V/1A
power waste:. <=24W
Input signal: DMX512
Transmission rate: 250Kpcs
Occupation address: 8 (after setting the first address, 8 consecutive addresses can be set within the range of 1-127)
Output load: 8-way maximum 16A/250VAC (resistive load)
Working temperature: -20 ℃ -70 ℃
Relative humidity: 10-90%
Weight: 650g
