4 channels IOT relay 16A/250VAC x4 controller

Detailed

Product Name: 4 channels IOT relay 16A/250VAC x4 controller

Model: ctt-ior16-4

Input voltage: DC24 / 1A

Power: < 10W

Input interface: SBUs

Relay: 4 channels do (max.16a resistive load or max.10a inductive load)

Input: di (dry contact signal or DC Voltage 5V ~ 36V signal)

Product size: 160mm x 90mm x 65mm

Working temperature: - 20 ～ 70 ℃

Relative humidity: 10-90%

Weight: 500g

4 channels IOT relay controller 16A X4

Adopt 32 bit low power consumption high speed CPU;

SBUs intelligent bus interface, up to 1200 meters;

4 independent relay outputs, including 2 outputs with normally open and normally closed terminals, which can realize interlocking control function;

Each relay has its own manual control function, which can control the maximum 16A resistive load or the maximum 10A inductive load;

4 channels of Di signal input, supporting dry contact signal or DC Voltage 5V ~ 36V signal;

Have timing control and timing control functions;

Group and scene functions;

Support on-line remote fixed upgrade, convenient engineering power customization, upgrade and update functions without removing the equipment;

Standard 35mm international guide rail installation;

Classification:16A/250V
