Product: Four channel 16A DALI relay Dali switch controller
Model: VH-DLR16-4
Input voltage: DC24V/1A
Power dissipation: <=24W
Input signal: DALI does not distinguish polarity (conforms to the DALI protocol standard in IEC62386; can be connected with any device conforming to the DALI protocol with a bus control)
Relay control: 16A/250VAC *4, (resistive load maximum 16A or inductive load maximum 10A)
Operating temperature: -20 DEG C, -75 DEG C
Relative temperature: 10-90%
Weight: 110g
Conforms to the DALI protocol standard in IEC62386. It can be connected with any DALI protocol device with a bus control;
DALI communication interface has isolation protection function
With four channel relay, resistive load maximum 16A or inductive load maximum 10A;
Inductive device such as controllable motor;
Guide type installation
Apply to family, office, hotel, engineering, etc.
