DALI to PWM Signal Convertor with relay switch

Detailed

Product：DALI Signal Convertor,DALI to PWM with relay switch

Model: CTT-DSC-DP-1RN

Input voltage : AC90 ~ 240V 50Hz/60Hz

 Power consumption : <5W

 input signal : DALI

 Dimming levels : 254

 Dimming range : 0% - 100% ( 0% off, 1 % to 100 % adjustable )

 Output Signal : 10V PWM

 Output signal maximum sink current : 50mA

 Output signal Maximum current source: 1mA

 Signal output error : PWM +5%

 Electronic switch Maximum current : 5A/250V

 Working temperature : -20 ℃ -75 ℃

 Relative humidity :10- 90%

 Weight : 110g

DALI PWM Signal Convertor

With PWM dimming power / ballast , you can make your DALI signal lights achieve remote control.

ABS plastic enclosure;

Minimize the volume , easy installation place ;

Comply with IEC62386 DALI protocol standards , can be used with any device complies with DALI protocol linked to a bus control ;

With 10V PWM signal output

Have a signal output and 1 channel electronic switch interfaces

DALI communication interface with isolation protection

PWM signal applied to PWM electronic dimming ballasts

For home, office, hotel , and engineering.

Classification:Converter
