SmartIoT relay controller 16A x4

Product:SmartIoT relay controller 16A x4

Model: VH-IOR16-4

Input voltage: DC24/1A

Power: <10W

Input interface: SBUS

Relay: 8  channels DO (Max.16A resistive load or Max.10A inductive load)

Input: DI (dry contact signal or DC voltage 5V~36V signal)

Product size: 160mm, x, 90mm, x65mm

Operating temperature: -20 ~ 70 DEG C

Relative humidity: 10-90%

Weight: 500g

The use of 32bit low power high-speed CPU;

The 100M/10M adaptive Ethernet interface;

The 8  channels relay output, which has 4 road with normally open and normally closed output, can realize interlocking control function;

Is each relay with manual control function, can control the maximum 16A resistive load or inductive load maximum 10A;

The 8 DI signal input, support dry contact signal or DC signal voltage 5V~36V;

Is a set of SBUS bus control relay output, can be extended to more devices;

Is a set of RS485 bus input / output, can customize the interface parameters of speed and direction, and support the third party system integration or control RS485 interface equipment;

The timing control and timing control function;

The scene with packet and function;

To support remote online upgrade fixed, custom power engineering is convenient, without removing the device that can upgrade capabilities;

The fire linkage interface with signal.

The international standard 35mm installation guide way;
