330mAx3 Constant current DALI LED Dimming Driver

Detailed

Product:DALI LED Dimming Driver,330mAx3 three channel Constant current

Model:CTT-DL2035-3

Supply power: DC12V ~ 48V

Power consumption: < = 50 mA (static)

Light signal input: DALI, interface absorbance current < 2 mA

Dimmable grade: 255

Dimming range: 0% 100% (0% off, and 1% ~ 100% adjustable)

Output current: 330mA

Output channel: 3

Output power: DC9V ~ 42V (Supply power > Output power)

Address assignment way: To be automatic allocated by DALI host

Working temperature: -20 ℃ to 75 ℃

Relative humidity: 10-90%

G.W.: 110g

DALI Dimming Driver

ABS plastic shell, with a terminal blocks protection waterproof cover;

Volume to minimize, easy to install place;

Operate in low voltage, safe and reliable;

Independent three channel output driver optional with constant current 330mA;

Meet the IEC62386 DALI protocol standards, and share one bus control with any equipment that accord with DALI protocol；

Applicable to family, office, hotel, landscape, billboards engineering, etc.

Classification:Driver
